Product
LingYI-1 VTOL Fixed-Wing UAV
Vertical takeoff · 2,000 km range · 40 kg payload
A large VTOL fixed-wing UAV built for industrial inspection, security reconnaissance and emergency response. 3 m wingspan, fuel-electric hybrid power breaks battery limits, 2,000 km single-sortie coverage at 180 km/h cruise — operating from urban streets to remote terrain with no runway.
Key features
01
VTOL + cruise dual-mode
Takes off and lands in place with no runway; switches to fixed-wing for 180 km/h economy cruise — flexible deployment and long-range work in one airframe.
02
2,000 km extended range
Fuel engine + onboard battery hybrid breaks battery-only limits — a single sortie covers 100+ km of linear infrastructure.
03
Large payload, multi-mission
40 kg payload simultaneously carries optical/thermal cameras, loudspeakers and release mechanisms for multi-task missions.
Business value
For pipeline inspection, one LingYI-1 replaces a 3–5 person crew, cuts per-sortie cost by 95%+, saves ¥0.5–0.8M/year in O&M, payback 8–16 months.
Technical specifications
Dimensions & weight
- Wingspan
- 3 m
- Length
- 2.8 m
- Empty weight
- 140 kg
- Max payload
- 40 kg
Flight performance
- Cruise speed
- 180 km/h
- Max speed
- 200 km/h
- Max range
- 2000 km
- Service ceiling
- 3000 m
Environment & control
- Wind resistance
- Force 6
- Control range
- 10 km
Powertrain
- Power source
- Fuel engine + onboard battery
- Endurance edge
- Dual supply beyond battery limits
Takeoff & payload
- Takeoff / landing
- Vertical, runway-free
- Optional payload
- FPV / EO gimbal / loudspeaker / thermal imager
